A production-grade GitOps-managed Kubernetes homelab running on hybrid infrastructure — local ARM/x86 nodes and Oracle Cloud free-tier VMs. Built for real operational use: local LLM inference, AI agent infrastructure (MCP servers), workflow automation, monitoring, and self-hosted tooling.
All cluster state is declarative and GitOps-driven via Flux CD. No manual
kubectl applyin production paths.
| Homelab tour | MCP + OpenWebUI on Kubernetes | Grafana monitoring |
|---|---|---|
 |
 |
 |
| Kubernetes Homelab Walkthrough | MCP + OpenWebUI Integration | Grafana Monitoring Dashboard |
┌─────────────────────────────────────────────────────────────────┐
│ KUBERNETES CLUSTER │
├─────────────────────────────────────────────────────────────────┤
│ Control Plane: orangepi6plus (192.168.8.236) │
│ │
│ Workers: │
│ • quinn-hpprobook430g6 (192.168.8.162) - Main workloads │
├─────────────────────────────────────────────────────────────────┤
│ Networking: Calico (VXLAN) │
│ GitOps: Flux CD │
│ Ingress: NGINX + MetalLB (192.168.8.40-192.168.8.99) │
└─────────────────────────────────────────────────────────────────┘
Key design decisions:
- Flux CD for GitOps — all reconciliation is pull-based from this repo
- Calico VXLAN for pod networking across heterogeneous node hardware
- MetalLB for bare-metal LoadBalancer IPs (no cloud LB dependency)
- SOPS + Age for secret encryption — secrets committed to git, never plaintext
- HelmRelease + Kustomization layering for environment-specific overrides
| Service | URL | Description |
|---|---|---|
| OpenWebUI | http://openwebui.k8s.local | Local LLM chat interface (Ollama backend) |
| Grafana | http://grafana.k8s.local | Dashboards & monitoring |
| Prometheus | http://prometheus.k8s.local | Metrics collection & alerting |
| n8n | http://n8n.k8s.local | Workflow automation & AI pipelines |
| changedetection.io | http://changedetection.k8s.local | Growth OS page-change triggers (LAN UI; ClusterIP for n8n) |
| Homepage | http://homepage.k8s.local | Service dashboard |
| Ansible AWX | http://awx.k8s.local | Automation & config management |
| Phoenix | http://phoenix.k8s.local | LLM observability |
| Paperclip | https://paperclip.k8s.local | AI-agent organization/orchestration control plane |
| MCPO Gateway | http://mcpo.k8s.local/docs | OpenAPI proxy for MCP servers |
| Context Forge | http://mcp.k8s.local | Dynamic MCP server hub |
K8SHomelab/
├── apps/base/ # Kubernetes manifests (HelmReleases, Deployments, ConfigMaps)
│ ├── grafana/ # Grafana + pre-built dashboards
│ ├── prometheus/ # Prometheus HelmRelease + alerting rules
│ ├── openwebui/ # Local LLM chat interface
│ ├── mcp-servers/ # Context Forge, MCPO gateway, Ansible MCP
│ ├── ansible/ # Ansible AWX operator deployment
│ ├── n8n/ # n8n workflow automation
│ └── ... # Additional apps
├── clusters/my-homelab/ # Flux Kustomization entrypoints
├── scripts/ # Cluster bootstrap and maintenance scripts
└── docs/ # Network, security, and architecture documentation
This cluster runs a self-hosted Model Context Protocol (MCP) stack, making local and cloud LLMs agent-capable against real infrastructure:
- MCPO Gateway — OpenAPI-compatible proxy that exposes MCP servers as REST endpoints, enabling any LLM client to call them without native MCP support
- Context Forge — Dynamic MCP server hub for routing agent requests to the right backend
- OpenWebUI — Frontend for local Ollama models with tool-use and agent pipeline support
- n8n — Low-code AI workflow automation, integrated with MCP endpoints and external APIs
- Phoenix — LLM observability: traces, evals, and prompt monitoring
- Paperclip — AI-agent business/control-plane layer for goals, org structure, work, budgets, approvals, and execution coordination
git add -A && git commit -m "message" && git push
flux reconcile kustomization apps --with-sourcekubectl get pods -n apps -o wide
flux get all -A192.168.8.40 homepage.k8s.local openwebui.k8s.local grafana.k8s.local prometheus.k8s.local n8n.k8s.local changedetection.k8s.local mcpo.k8s.local mcp.k8s.local pgadmin.k8s.local qdrant.k8s.local awx.k8s.local jupyter.k8s.local phoenix.k8s.local mongo-express.k8s.local authentik.k8s.local redisinsight.k8s.local groupme.k8s.local
- Secrets managed via SOPS with Age encryption — encrypted at rest, safe to commit
- Credentials stored in encrypted
postgres-credentialsand per-app secrets - No hardcoded values in any manifest
- Detailed guide: docs/SECURITY.md
| Document | Description |
|---|---|
| AGENT_CONTEXT.md | Context file for AI agents working in this repo |
| SETUP_SUMMARY.md | Complete cluster setup guide |
| FLUX_JENKINS_INTEGRATION.md | Flux + Jenkins CI/CD integration |
| docs/NETWORK.md | Network architecture & IP allocation |
| apps/base/mcp-servers/README.md | MCP server deployment guide |
| apps/base/paperclip/README.md | Paperclip deployment, architectural role, and productionization guidance |
| docs/SUPABASE_KNOWLEDGE_LAYER_REFERENCE.md | Reference Postgres + pgvector business-knowledge layer and Drive sync/ACL pattern |
| docs/GROWTH_OS_INFRASTRUCTURE.md | Homelab runtime boundary for Growth OS (n8n, Paperclip, SearXNG, changedetection) |
| Issue | Cause | Fix |
|---|---|---|
| DNS resolution failures | CoreDNS not scaling under load | See NETWORK_TROUBLESHOOTING.md |
| Layer | Technology |
|---|---|
| Orchestration | Kubernetes (bare-metal kubeadm) |
| GitOps | Flux CD v2 |
| Networking | Calico (VXLAN), MetalLB, NGINX Ingress |
| Package Management | Helm, Kustomize |
| Secrets | SOPS + Age |
| Monitoring | Prometheus, Grafana |
| AI/LLM | OpenWebUI, Ollama, Phoenix |
| MCP | MCPO, Context Forge |
| Automation | n8n, Ansible AWX |
| Agent orchestration | Paperclip |
| Storage | Local PVs, PostgreSQL, Qdrant, Redis, MongoDB |
| Auth | Authentik (SSO) |
| Infrastructure | Oracle Cloud (free tier VMs), local ARM/x86 nodes |
Part of a broader homelab + automation ecosystem. See TerraformHomeLab for the IaC layer.
